BIRCOslot (Monolithic concrete slot channel)

  • Description
  • Ask for a quote about this product

Description

Catalogue: BIRCO_CONCRETE_SLOT_CHANNELS ENG   BIRCOslot PFUHLER AIRPORT CATALOG ENG

BIRCOslot Solidrain S ja Pfuhler slot channels | Long service life – utmost stability

BirCOslot channel systems Solidrain S and Pfuhler provide long-lasting sealing against fluids such as fuels, oils, alkali and acids. The monolithic reinforced concrete body can withstand extreme loads and greatly reduces costs and installation time.

Facts about the BIRCOslot Solidrain S slot channel:

+ Type I slot channel system:

Round profiles: DN 200; 300

Oval profiles: 300/400

+ Monolithic concrete body (C 40/50)

+ Conical slot 30/50 (intermittent)

+ Inlet-optimised, inclined surface

+ Installation length: 4.00 m (other lengths on request)

+ Outfall-unit (1.00 m) and maintenance channel (1.00 m) with removable ductile iron cover

+ Load class A15–C250

Main areas of application of BIRCOslot Solidrain S:

+ Traffic areas

+ Main longitudinal traffic areas

+ Emergency lanes, tunnels

+ Areas related to agricultural activity

+ Pedestrian areas, marketplaces, urban depots

+ Car parks

Facts about the BIRCOslot Pfuhler slot channel:

+ Type I slot channel system:

Round profiles: DN 200; 300; 400; 500

Oval profiles: 300/400; 300/400

+ Monolithic constructively reinforced concrete body (C 40/50)

+ Conical slot 30/50 (continuous or intermittent)

+ Plane or inclined surface

+ Outfall-unit (1.00 m) and maintenance channel (1.00 m) with removable ductile iron cover

+ Load class A15–D400 or A15–F900

Main areas of application of BIRCOslot Pfuhler:

+ Heavy machinery loading areas

+ Logistics centres operating forklift trucks

+ Large-scale agricultural operations

+ Transversal and longitudinal traffic areas

+ Truck parking

+ Airports

You can find the full range of BIRCOslot products by opening the catalogue.

For BiRCOslot channels, we create quotes on a project basis. Please contact us for more information.
